The Pipeline Intelligent Metal Detector is an intelligent metal detection equipment developed by using digital intelligent technology, which realizes the full digitalization and intelligence of metal detection technology, and is used to detect metal scraps, broken needles, iron wires, lead, copper, aluminum, tin, stainless steel and other metal impurities that are mixed or lost in raw materials or products.Dynamic Professional Metal Detector has excellent performance, simple operation and wide application industries.Welcome to consult for quotation information!
Detection sensitivity: Fe ￠ 0.6mm
Detection surface width: 400mm Detection height: 100mm
Alarm mode: buzzer, elimination mode
Conveying speed: 25m/min (50HZ)
Power supply: AC220V/380V 50-60HZ
Power: about 200W
Overall dimension: 1800mm (L) * 680mm (W) * 850mm (H)
Weight: about 160Kg
For reference only, please consult for details!
Contact us to recommend a product that is suitable for you!
1. Function: set various required functions and modes, and set self-test function.
2. Sensitivity: divided gears, adjustable to increase or decrease (1-63 gears adjustable).
3. The electric frequency display sensitivity can be adjusted to reflect the metal index.
5. When trace metal is detected, the sound, light and instrument will alarm at the same time, and the unqualified products will automatically stop.
6. It has self-check function, which can check whether the instrument is normal by itself to avoid unnecessary maintenance.
7. The whole machine is made of industrial stainless steel, waterproof, rust-proof, sanitary and easy to clean.
8. The conveyor belt is environmentally friendly. The food-grade conveyor belt is applicable to the temperature range of - 20C to 65C, which is convenient for working in the cold storage area.
9. Combined miniature subwoofer environment-friendly motor, continuous use without failure.
10. It has leakage protection function and high safety factor.
Inner use the plastic wrapping ,out package will use stronger wooden cases.
Our standard package process:
1) Dust & Cleaning
2) Lubricate Drive Parts
3) Divide Machine Into Modules
4) Wrap Modules With Plastic Film
5) Packing Modules into Plywood Cases
6) Mark Shipping Mark In The Cases
If any special requirements, we will pack it as requested.
Q1. Are you a manufacturer or trader?
A: We are a manufacturer and we are located in Shanghai,China. We have our own design team for product design.
Q2: Can you explain the whole transaction process?
1. Understand the specific needs of customers and determine the machine details.
2. Sign the contract.
3. Pay the deposit.
4. The factory arranges production.
5. Test and inspect the machine before shipment.
6. Check by customers through online or on-site testing.
7. Shipment and transportation, balance payment.
Q3.How much does Metal Detector cost?
There is no quick, easy answer to this question.Our machine is specific to the customer, so arriving at 'standard pricing' isn't usually practical. Pricing largely depends upon your unique needs, such as the products you want to detect, the size of the product,the speed you want to achieve,or the complexity of the processv. Contact us to get a specific quote.
Q4. What kind of shipping method can you provide?
A: By sea, by air and by international express.We will send the photo and video of machine to customer to check the machine running situation before delivery.
Q5. Do you accept customer logo and customization?
A: We accept all kinds of customization and logo for our customers for all our products.
Q6. How about the packing for product? Is it easy damaged during transportation?
A: No.We takes of wooden case and it is very safe.
